Product Summary
The MB39C312PVK-G is a 4ch system power management IC. The MB39C312PVK-G consists of 2-ch DC/DC Converter and 2-ch Charge pump. The DC/DC converter has excellent line regulation with the feed-forward method. Moreover, SW FET and phase compensator (Buck) is included, so that BOM can be reduced. It is most suitable for large size LCD panel power supply. The applications of the MB39C312PVK-G include TFT LCD panels for LCD TV sets and monitors.
Parametrics
MB39C312PVK-G absolute maximum ratings: (1)Power supply voltage, VDD: -0.3 to +17 V; VBOOT: -0.3 to +19.8 V; VSUP: -0.3 to +19.8 V; (2)Input voltage, VFB FB: -0.3 to + 7V; VOS: -0.3 to +19.8 V; VGD: -0.3 to +19.8 V; VEN: -0.3 to + 17 V; VFREQ: -0.3 to +17 V; (3)SW Voltage, VSWB: -0.7 to +17 V; VSW: -0.3 to +19.8 V; (4)SW peak current, ISWB: 3.9 A; ISW: 4.2 A; (5)Power dissipation, PD: 3.44W; (6)Storage temperature, TSTG: -55 to +125℃.
Features
MB39C312PVK-G features: (1)Power supply voltage range: 8 V to 14 V; (2)For Buck Converter included SW FET (Vlogic): output 1.8 V to 3.3 V 1.5 A Max; (3)For Boost Converter included SW FET (Vs): output 18.1 V Max 1.5 A Max (at 12 V input and 15 V output); (4)Negative Charge Pump with output voltage feedback (VGL): 50 mAMax; (5)Positive Charge Pump with output voltage feedback (VGH): 50 mAMax; (6)Error Amp threshold voltage: 1.213 V ± 1.5 % (Vlogic), 1.146 V ± 0.9 % (Vs),0 V ± 36 mV (VGL), 1.213 V ± 2.1 % (VGH); (7)Built-in soft-start circuit independent of loads; (8)Excellent line regulation by the feed-forward method (Vlogic, Vs); (9)Built-in phase compensator parts (Vlogic); (10)Built-in sequence comparator for rising; (11)Built-in short circuit protection (Vlogic); (12)Built-in over voltage protection (Vs); (13)Built-in over current protection (Vlogic, Vs); (14)Built-in over temperature protection; (15)Frequency setting by input pin: 500 kHz / 750 kHz.; (16)Package: TSSOP-28 Exposed PAD.
