S87C511

S87C511, 16-bit microcontroller, 13.0V, 1.5W, 16 MHz, QFP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1258 :	2.00 / Piece

PartNumber:: S87C511

Brand:: Intel Corporation - Intel | Pack: QFP | D/C: 00+

Availability:: Supply Ability: 0/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Helen Li's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-15

From Other Seller

Part Number:S87C511
US $2.00 - 2.00
Quantity:

piece

Product Summary

The S87C511 is a 16-bit microcontroller architecture. The S87C511 provides a high performance processor along with low power consumption. To further reduce power requirements, the processor can be placed into Idle or Powerdown Mode. Four high-speed capture inputs are provided to record times when events occur. Six high-speed outputs are available for pulse or waveform generation. The high-speed output can also generate four software timers or start an A/D conversion. Events can be based on the timer or counter. Also provided on-chip are an A/D converter, serial port, watchdog timer and a pulse-width-modulated output signal.

Parametrics

S87C511 absolute maximum ratings: (1)Am－ient Temperature under Bias: －55　to 125°C; (2)Storage Temperature : －65°Cto 150°C; (3)Voltage on VPP or EA to VSS or ANGND : －0.3V to 13.0V; (4)Voltage on Any Other Pin to VSS : －0.5V to 7.0V; (5)Power Dissipation(1): 1.5W．

Features

S87C511 features: (1)8 Kbytes of On-Chip OTPROM or ROM; (2)232 Byte Register File; (3)Register-to-Register Architecture; (4)28 Interrupt Sources/16 Vectors; (5)1.75 ms 16 x 16 Multiply (16 MHz); (6)3.0 ms 32/16 Divide (16 MHz); (7)Powerdown and Idle Modes; (8)16-Bit Watchdog Timer; (9)8-Bit External Bus; (10)16 MHz Standard; (11)Full Duplex Serial Port; (12)High Speed I/O Subsystem; (13)16-Bit Timer; (14)16-Bit Counter; (15)Pulse-Width-Modulated Output; (16)Four 16-Bit Software Timers; (17)10-Bit A/D Converter with Sample/Hold; (18)Extended Temperature Available．
