Product Summary
The ISL6612ACB-T is a high frequency MOSFET driver specifically designed to drive upper and lower power N-Channel MOSFETs in a synchronous rectified buck converter topology. The ISL6612ACB-T drives the upper gate to 12V, while the lower gate can be independently driven over a range from 5V to 12V. Applications of the ISL6612ACB-T include: Core Regulators for Intel and AMD Microprocessors, High Current DC-DC Converters and High Frequency and High Efficiency VRM and VRD.
Parametrics
ISL6612ACB-T absolute maximum ratings: (1) Supply Voltage (VCC) : 15V; (2) Supply Voltage (PVCC) : VCC +0.3V; (3) BOOT Voltage (VBOOT-GND) : 36V; (4) Input Voltage (VPWM) : GND -0.3V to 7V; (5) PHAS: GND -0.3VDC to 15VDC; (6) ESD Rating Human Body Model: Class I JEDEC STD.
Features
ISL6612ACB-T features: (1) Pin-to-pin Compatible with HIP6601 SOIC family; (2) Dual MOSFET Drives for Synchronous Rectified Bridge; (3) Advanced Adaptive Zero Shoot-Through Protection; (4) Advanced Adaptive Zero Shoot-Through Protection; (5) 36V Internal Bootstrap Schottky Diode; (6) Bootstrap Capacitor Overcharging Prevention; (7) Expandable Bottom Copper Pad for Enhanced Heat Sinking; (8) Three-State PWM Input for Output Stage Shutdown; (9) Dual Flat No-Lead (DFN) Package; (10) Pb-Free Plus Anneal Available (RoHS Compliant) .
