Product Summary
The MS2199-CAZ is a schottky barrier rectifier. The state-of-the-art geometry features epitaxial construction with oxide passivation and metal overlay contact.
Parametrics
MS2199-CAZ absolute maximum ratings: (1)Peak repetitive revere voltage, VRRM: 30V; (2)Working peak reverse voltage, VRWM: 30V; (3)DC blo9cking voltage, VR: 30V; (4)RMS reverse voltage, VR: 21V; (5)Average rectifier forward current, IO: 3A; (6)Peak repetitive forward curent, IFM: 3.0A; (7)Non-repetitive peak surge current, IFSM: 80A.
Features
MS2199-CAZ features: (1)Low forward voltage; (2)Low switching noise; (3)High current capacity; (4)Guarantee reverse avalance; (5)Guard-ring for stress protection; (6)Low power loss & High efficiency; (7)125℃ operating junction temperature; (8)Low stored charge majority carrier cnduction; (9)Plastic material used carries underwrites laboratory flammability classification 94V-O.
Diagrams
