Product Summary

The PMB6618RV2.1 is a Transceiver for Bluetooth FH-SS 2.4 GHz Systems.

Features

PMB6618RV2.1 features: (1)Bluetooth Transveiver for the 2.4 GHz ISM Band (RF range 2378-2497 MHz); (2)Part of complete Infineon Bluetooth chipset solution; (3)Completely integrated receiver with outstanding RF performance:; (4)best in class sensitivity and blocking; (5)Low current consumption; (6)No external IF filters or RF filters necessary; (7)B6HFC BiCMOS technology, 25 GHz ft; (8)fully balanced self adjusting VCO with integrated varactor diodes for receive and transmit mode; (9)Prescaler and PLL on-chip with 1 MHz charge pump reference frequency; (10)Supply voltage regulators for the VCO and the analogue part; (11)Internal current reference for PLL charge pump to get constant lock-in time; (12)Small outline P-TSSOP-38 package (PMB 6625) or very small VQFN 40 package (PMB6627); (13)low-if receiver topology solution Benefits: + no IF SAW-filter necessary or RF ceramic filter necessary + reduced component count; (14)2.5 GHz RF Power amplifier included, output power adjustable with external resistor, Benefits: + No external PA necessary for Bluetooth power class 2 operation; + direct interface to power class 1 PA via small matching circuits; + reduced RF front end component count; (15)On-chip LNA for optimum sensitivity and blocking; (16)70 dB RSSI dynamic range, high stability; (17)Data Slicer including specialized offset compensation or analogue output.
