Product Summary

The SPCA527A is a digital camera processor chip that provides a complete solution for dual mode camera applications. The SPCA527A integrates image sensor interface, digital video input interface, color image processor, storage media controller, JPEG image compression engine, USB interface, and a built-in micro-controller. The SPCA504A supports both CCD and CMOS image sensors up to 1.1M and 2.0M pixels respectively. It is designed to fulfill all the requirements for the dual mode camera applications. The SPCA527A camera processor chip includes not only the latest technology, but also the full services and support of Sunplus.

Features

SPCA527A features: (1)DSC mode : capture one frame each time; (2)Video clip mode : capture a video with frame rate 15~30 frames/sec; (3)PC-camera mode : 30 frames/sec for CIF size, 20 frames/sec for VGA size; (4)High quality color interpolation; (5)Two-dimensional edge enhancement; (6)Bad pixels concealment; (7)AE/AWB parameter windows cover full range of the sensor.

Diagrams

SPCA527A pin connection
