Product Summary

The TEA5764HN/N2 is a single chip electronically tuned FM stereo radio with Radio Data System (RDS) and Radio Broadcast Data System (RBDS) demodulator and RDS/RBDS decoder for portable application with fully integrated IF selectivity and demodulation. The radio is completely adjustment free and only requires a minimum of small and low cost external components. The radio can tune to the European, US and Japanese FM bands. It has a low power consumption and can operate at a low supply voltage.

Parametrics

TEA5764HN/N2 absolute maximum ratings: (1)VCO tuned circuit output 1: -0.3 to +8 V; (2)VCO tuned circuit output 2: -0.3 to +8 V; (3)digital supply voltage: -0.3 to +5.5 V; (4)analog supply voltage: -0.3 to +8 V; (5)voltage on all inputs and outputs: -0.3 to +5.5 V; (6)storage temperature: -55 to +150 ℃; (7)ambient temperature: -40 to +85 ℃.

Features

TEA5764HN/N2 features: (1)High sensitivity due to integrated low noise RF input amplifier; (2)FM mixer for conversion of the US/Europe (87.5 MHz to 108 MHz) and Japanese FM band (76 MHz to 90 MHz) to IF; (3)Preset tuning to receive Japanese TV audio up to 108 MHz; (4)Auto search tuning, raster 100 kHz; (5)RF automatic gain control circuit; (6)LC tuner oscillator operating with low cost fixed chip inductors; (7)Fully integrated FM IF selectivity; (8)Fully integrated FM demodulator;; (9)no external discriminator; (10)Crystal oscillator at 32768 Hz, or external reference frequency at 32768 Hz; (11)PLL synthesizer tuning system; (12)IF counter; 7-bit output via the I2C-bus; (13)Level detector; 4-bit level information output via the I2C-bus; (14)Soft mute: signal dependent mute function; (15)Mono/stereo blend: gradual change from mono to stereo, depending on signal; (16)Adjustment-free stereo decoder; (17)Autonomous search tuning function; (18)Standby mode; (19)MPX output; (20)One software programmable port; (21)Fully integrated RDS/RBDS demodulator in accordance with EN50067.

Diagrams

TEA5764HN/N2 pin connection
