Product Summary

The TW9909BATA2-GR analog front-end is equipped with three separate analog channels that enable it to accept all three possible analog video signal standards: composite, S-video or YPbPr component video. The TW9909BATA2-GR is possible to connect up to six composite inputs at one time and allow the software to switch between them. The front-end contains all the necessary circuits to simplify the system design. AGC and clamping circuits, and three 9-bit analog-todigital converters (ADCs) convert inputs into digital signals for processing.

Parametrics

TW9909BATA2-GR absolute maximum ratings: (1)Type: NTSC/PAL/SECAM Video Decoder; (2)Applications: Multimedia; (3)Mounting Type: Surface Mount; (4)Package / Case: 100-LQFP; (5)Voltage - Supply, Analog: 3.3V; (6)Voltage - Supply, Digital: 3.3V.

Features

TW9909BATA2-GR features: (1)Analog Video Decoder and Analog Component Input; (2)Video processing; (3)Video Output; (4)Miscellaneous.

Diagrams

TW9909BATA2-GR pin connection
