Product Summary
The DSPB56720AG Serial Network Interface Controller for wisted Pair (ST-NIC)is a microCMOS VLSI deviced designed for east implementation of CSMA/CD local area networks. The 10BASE-T transceiver of the DSPB56720AG fully complies with the IEEE standard.
Parametrics
DSPB56720AG absolute maximum ratings: (1) Supply Voltage(Vcc) : -0.5 to +7.0V; (2) DC Input Voltage (VIN) : -0.5 to Vcc +0.5V; (3) DC Output Voltage (VOUT) : -0.5 to Vcc +0.5V; (4) Storage Temperature Range (TSTG) : -65 to +150°C; (5) Power Dissipation (PD): 800mW; (6) Lead Temp. (TL) : 260°C; (7) ESD Rating (RZAP=1.5k, CZAP=100pF) ; (8) Clamp Diode Current: ±20mA.
Features
DSPB56720AG features: (1) Single chip solution for IEEE802.3, 10base-T; (2) Integrated ENDEC, and transceiver; (3) Full AUI interface; (4) No external precision components required; (5) 3 levels of loopback supported.
