Product Summary
The HIP6018CB-T is an advanced PWM and dual linear power controller. The HIP6018CB-T provides the power control and protection for three output voltages in high-performance microprocessor and computer applications. The HIP6018CB-T integrates a PWM controllers, a linear regulator and a linear controller as well as the monitoring and protection functions into a single package. Applications of the HIP6018CB-T include: Full Motherboard Power Regulation for Computers and Low-Voltage Distributed Power Supplies.
Parametrics
HIP6018CB-T absolute maximum ratings: (1) Supply Voltage, VCC: +15V; (2) PGOOD, RT, FAULT, and GATE Voltage GND/; -0.3V to Vcc +0.3V; (3) Input, Output or I/O Voltage: GND -0.3V to 7V; (4) Supply Voltage, Vcc: +12V, ±10%; (5) Ambient Temperature Range: 0 to 70°C; (6) Junction Temperature Range.: 0 to +125°C.
Features
HIP6018CB-T features: (1) Provides 3 Regulated Voltages; (2) Drives N-Channel MOSFETs; (3) Operates from +3.3V, +5V and +12V Inputs; (4) Simple Single-Loop PWM Control Design; (5) Fast Transient Response; (6) Excellent Output Voltage Regulation; (7) Over-Voltage and Over-Current Fault Monitors; (8) Small Converter Size.
Diagrams
