PIC16C926-I/L

PIC16C926-I/L, EPROM/ROM-based CMOS microcontroller, PLCC, 0V to +7.5V, 300mA, Microchip Technology

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.10~2.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1140 :	2.10 / Piece

PartNumber:: PIC16C926-I/L

Brand:: Microchip Technology - Microchip | Pack: PLCC | D/C: 03+

Availability:: Supply Ability: 0/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Helen Li's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-12

From Other Seller

Part Number:PIC16C926-I/L
US $2.10 - 2.10
Quantity:

piece

Product Summary

The PIC16C55AT-04I/SS044 is a low cost, high performance, 8-bit fully static, EPROM/ROM-based CMOS microcontroller. It employs a RISC architecture with only 33 single word/single cycle instructions. All instructions are single cycle except for program branches which take two cycles. The PIC16C55AT-04I/SS044 delivers performance in an order of magnitude higher than its competitors in the same price category.

Parametrics

PIC16C926-I/L absolute maximum ratings: (1)Ambient temperature under bias: -55℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on any pin with respect to VSS (except VDD, MCLR, and RA4): -0.3V to (VDD + 0.3V); (4)Voltage on VDD with respect to VSS: 0V to +7.5V; (5)Voltage on MCLR with respect to VSS: 0V to +13.25V; (6)Voltage on RA4 with respect to VSS: 0V to +8.5V; (7)Voltage on VLCD2, VLCD3 with respect to VSS: 0V to +10V; (8)Total power dissipation: 1.0 W; (9)Maximum current out of VSS pin: 300 mA; (10)Maximum current into VDD pin: 250 mA; (11)Input clamp current, IIK (VI < 0 or VI > VDD): ±20 mA; (12)Output clamp current, IOK (VO < 0 or VO > VDD): ±20 mA; (13)Maximum output current sunk by any I/O pin: 25 mA; (14)Maximum output current sourced by any I/O pin: 25 mA; (15)Maximum current sunk by all Ports combined: 200 mA; (16)Maximum current sourced by all Ports combined: 200 mA.

Features

PIC16C926-I/L features: (1)Only 35 single word instructions to learn; (2)All single cycle instructions except for program branches which are two-cycle; (3)Operating speed: DC - 20 MHz clock input DC - 200 ns instruction cycle; (4)Up to 8K x 14-bit words of EPROM program memory, 336 bytes general purpose registers (SRAM), 60 special function registers; (5)Pinout compatible with PIC16C923/924.
