Product Summary
The S29PL032J60BFI120E is a 128/128/64/32 Mbit, 3.0 volt-only Page Mode and Simultaneous Read/Write Flash memory device organized as 8/8/4/2 Mwords. The S29PL032J60BFI120E offers fast page access times of 20 to 30 ns, with corresponding random access times of 55 to 70 ns, respectively, allowing high speed microprocessors to operate without wait states. To eliminate bus contention the S29PL032J60BFI120E has separate chip enable (CE#), write enable (WE#) and output enable (OE#) controls. Note: Device PL129J has 2 chip enable inputs (CE1#, CE2#).
Parametrics
S29PL032J60BFI120E absolute maximum ratings: (1)Storage Temperature Plastic Packages: –65°C to +150°C; (2)Ambient Temperature with Power Applied: –65°C to +125°C; (3)VCC: –0.5 V to +4.0 V; (4)A9, OE#, and RESET#: –0.5 V to +13.0 V; (5)WP#/ACC: –0.5 V to +10.5 V; (6)All other pins: –0.5 V to VCC +0.5 V; (7)Output Short Circuit Current: 200 mA.
Features
S29PL032J60BFI120E features: (1)128/128/64/32 Mbit Page Mode devices; (2)Page size of 8 words: Fast page read access from random locations within the page; (3)Single power supply operation; (4)Full Voltage range: 2.7 to 3.6 volt read, erase, and program operations for battery-powered applications; (5)Dual Chip Enable inputs (only in PL129J); (6)Two CE# inputs control selection of each half of the memory space; (7)Simultaneous Read/Write Operation; (8)Both top and bottom boot blocks in one device; (9)Manufactured on 110 nm process technology; (10)Data Retention: 20 years typical; (11)Cycling Endurance: 1 million cycles per sector typical.
Diagrams
