Product Summary

The XCV100-4PQ240C is a Field Programmable Gate Array. It delivers high-performance, high-capacity programmable logic solutions. Dramatic increases in silicon efficiency result from optimizing the new architecture for place-and-route efficiency and exploiting an aggressive 5-layer-metal 0.22 mm CMOS process. These advances make the XCV100-4PQ240C powerful and flexible alternatives to mask-programmed gate arrays. The XCV100-4PQ240C delivers a high-speed and high-capacity programmable logic solution that enhances design flexibility while reducing time-to-market.

Parametrics

XCV100-4PQ240C absolute maximum ratings: (1)VCCINT, Supply voltage relative to GND: –0.5 to 3.0 V; (2)VCCO, Supply voltage relative to GND: –0.5 to 4.0 V; (3)VREF, Input Reference Voltage: –0.5 to 3.6 V; (4)VIN, Input voltage relative to GND: Using VREF: –0.5 to 3.6 V; Internal threshold: –0.5 to 5.5 V; (5)VTS, Voltage applied to 3-state output: –0.5 to 5.5 V; (6)VCC, Longest Supply Voltage Rise Time from 1V-2.375V: 50 ms; (7)TSTG, Storage temperature (ambient): –65 to +150 ℃ ; (8)TJ, Junction temperature: Plastic Packages: +125 ℃.

Features

XCV100-4PQ240C features: (1)Fast, high-density Field-Programmable Gate Arrays: Densities from 50k to 1M system gates; system performance up to 200 MHz; 66-MHz PCI Compliant; Hot-swappable for Compact PCI; (2)Multi-standard SelectIO interfaces: 16 high-performance interface standards; Connects directly to ZBTRAM devices; (3)Built-in clock-management circuitry: Four dedicated delay-locked loops (DLLs) for advanced clock control; Four primary low-skew global clock distribution nets, plus 24 secondary local clock nets; (4)Hierarchical memory system: LUTs configurable as 16-bit RAM, 32-bit RAM, 16-bit dual-ported RAM, or 16-bit Shift Register; Configurable synchronous dual-ported 4k-bit RAMs; fast interfaces to external high-performance RAMs.

Diagrams

XCV100-4PQ240C pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
XCV100-4PQ240C
XCV100-4PQ240C


IC FPGA 2.5V C-TEMP 240-PQFP

Data Sheet

Negotiable
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
XCV100
XCV100

Other


Data Sheet

Negotiable
XCV1000-4BG560C
XCV1000-4BG560C


IC FPGA 2.5V C-TEMP 560-MBGA

Data Sheet

Negotiable
XCV1000-4BG560I
XCV1000-4BG560I


IC FPGA 2.5V I-TEMP 560-MBGA

Data Sheet

Negotiable
XCV1000-4FG680C
XCV1000-4FG680C


IC FPGA 2.5V C-TEMP 680-FBGA

Data Sheet

Negotiable
XCV1000-4FG680I
XCV1000-4FG680I


IC FPGA 2.5V I-TEMP 680-FBGA

Data Sheet

Negotiable
XCV1000-4HQ240I
XCV1000-4HQ240I

Other


Data Sheet

Negotiable
