Product Summary

The HM5118160CJI6 is CMOS dynamic RAM organized as 1,048, 576 word×16-bit. The HM5118160CJI6 employs the most advanced CMOS technology for high performance and low power. The HM5118160CJI6 offers Fast Page Mode as a high speed access mode.

Parametrics

HM5118160CJI6 absolute maximum ratings: (1) voltage on any pin relative to Vss, VT: -1.0 to +7.0V; (2) Supply voltage relative to Vss, Vcc: -1.0 to +7.0V; (3) Short circuit output current IOUT: 50mA; (4) Power dissipation PT: 1.0W; (5) Operating temperature Topr: 0 to +70°C; (5) Storage temperature Tstg: -55 to +125°C.

Features

HM5118160CJI6 features: (1) single 5V (±10%) ; (2) Access time: 50ns/60ns/70ns; (3) Power disispation: 1100mW/935mw/825mW; (4) fast page mode capability; (5) refresh cycles; (6) 4 variations of refresh; (7) Battery backup operation (L-version) .

Diagrams

HM5118160CJI6 Pin Configuration
