TOP244YN

TOP244YN, intergrated off-line switcher, 700V, 2.16A, TO

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.40~0.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 570 :	0.40 / Piece

PartNumber:: TOP244YN

Brand:: Power IC Ltd. - Power | Pack: TO | D/C: 10+

Availability:: Supply Ability: 0/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Helen Li's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-22

From Other Seller

Part Number:TOP244YN
US $0.40 - 0.40
Quantity:

piece

Product Summary

The TOP244YN is an extended power, design flexible, Ecosmart, intergrated off-line switcher. All package types of the TOP244YN provide the following transparent features: soft-start, 132kHz switching frequency (automatically reduced at light load), frequency jittering for lower EMI, wider DCmax hysteretic thermal shutdown, and larger creepage packages.

Parametrics

TOP244YN absolute maximum ratings: (1) Drain voltage: -0.3V to 700V; (2) Drain peak current: 2.16A; (3) control voltage: -0.3V to 9V; (4) Control current: 100mA; (5) line sense pin voltage: -0.3V to 9V; (6) current limited pin voltage: -0.3V to 4.5V; (7) frequency pin voltage: -0.3V to 9V; (8) storage temperature: -65°C to 150°C; (9) operating junction temperature: -40°C to 150°C; (10) lead temperature: 260°C.

Features

TOP244YN features: (1) Extended power range for higher power applications; (2) No heatsink required up to 34 W using P package; (3) Features eliminate or reduce cost of external components ; (4) Fully integrated soft-start for minimum stress/overshoot; (5) Externally programmable accurate current limit ; (6) Wider duty cycle for more power, smaller input capacitor; (7) Separate line sense and current limit pins on Y/R/F packages; (8) Line under-voltage (UV) detection: no turn off glitches; (9) Line overvoltage (OV) shutdown extends line surge limit; (10) Line feed-forward with maximum duty cycle (DCMAX) reduction rejects line ripple and limits DCMAX at high line ; (11) Frequency jittering reduces EMI and EMI fltering costs; (12) Regulates to zero load without dummy loading; (13) 132 kHz frequency reduces transformer/power supply size; (14) Half frequency option in Y/R/F packages for video applications; (15) Hysteretic thermal shutdown for automatic fault recovery; (16) Large thermal hysteresis prevents PC board overheating.
